Model No.: MS5215
The MS5215 is the simplest unit available in the Mastech Advanced line of insulation resistance testers. The unit is capable of testing insulation resistance up to 5kV output DC voltage and 5TΩ resistance. The MS5215 comes standard with a range of new features and design updates which make it easy to use daily in professional settings.
| Insulation | ||
|---|---|---|
| Operating Voltage | Measuring Range | Accuracy |
| 250V DC | 0.01MΩ ~2.5GΩ | ±(5%+5) |
| 2.51GΩ ~250GΩ | ±(20%+10) | |
| 500V DC | 0.01M Ω~5.0GΩ | ±(5%+5) |
| 5.01GΩ~500GΩ | ±(20%+10) | |
| 1000V DC | 0.01M Ω~10GΩ | ±(5%+5) |
| 10.01GΩ~500GΩ | ±(20%+10) | |
| 501GΩ~999GΩ | ±(30%+20) | |
| 2.5KV DC | 0.01M Ω~25GΩ | ±(5%+5) |
| 25.1GΩ~500GΩ | ±(20%+10) | |
| 501GΩ~999GΩ | ±(30%+20) | |
| 1TΩ~2.5TΩ | ±(30%+40) | |
| 5KV DC | 0.01M Ω~50GΩ | ±(5%+5) |
| 50.1GΩ~500GΩ | ±(20%+10) | |
| 501GΩ~999GΩ | ±(30%+20) | |
| 1TΩ~5TΩ | ±(30%+40) | |
| Leakage Current | ||
| Range | Measuring Range | Accuracy |
| 10nA | 1.00nA~9.99nA | ±(15%+1nA) |
| 100nA | 9.0nA~99.9nA | ±(15%+5) |
| 1000nA | 100nA~999nA | |
| 10μA | 0.90μA~9.99μA | |
| 100μA | 9.0μA~99.9μA | ±(2.5%+5) |
| 1000μA | 90μA~999μA | |
| 3mA | 0.90m A~3.00m A | |
| Resistance | ||
| Range of Insulation | Range of humidity | Range of temperature |
| 0Ω~100M Ω | <85% RH | |
| 101Ω~20GΩ | <75% RH | 23°C ±5°C |
| 21GΩ~500GΩ | <65% RH | 73°F ±9°F |
| 501GΩ~5TΩ | <55% RH | |
| Voltage | ||
| Test Mode | DC Voltage | AC Voltage |
| Test Range | ±(50V~1000V) | ±50V~750V(50Hz ~60Hz ) |
| Precision error | ±(5%+5) | ±(5%+5) |
| Input Resistance | Approx . 10M Ω | Approx . 10M Ω |
| Temperature | ||
| Measuring Range | Measuring Precision Accuracy | |
| -10°C~0°C | ±1.5°C | |
| 0°C~40°C | ±2.0°C | |
| 40°C~70°C | ±1.5°C | |
| General | ||
| Power Supply | 6× Lr14(2#) Batteries , or 6× 1.2V AA Batteries | |
| (Charger: Input Voltage 100V~240V) | ||
| Product Size | 284mm× 230mm× 125mm /11.2"× 9.1"× 4.9" | |
| Product Weight | 2426g/5.34lb | |
| Certificate | CE/ETL/RoHS | |
| Safety Rating | CAT III 1000V/CAT IV 600V | |
